Application Characteristics of AUO Liquid Crystal Module T420HVN08.0
Basic Information: Brand Model Name Screen Type Other Names
AUO T420HVN08.0 a-Si TFT-LCD, Liquid Crystal Module -
Maximum Ratings: RoHS Operating Temperature Storage Temperature Vibration Resistance
RoHS Compliance 0 ~ 50 °C -20 ~ 60 °C -
Suitable for: Television, Digital Signage
Pixel Configuration Dot Pitch (W×H) Pixel Spacing (W×H)
1920(RGB)×1080, FHD RGB Vertical Stripes 0.1615×0.4845 mm 0.4845×0.4845 mm [52PPI]
Structural Dimensions: Display Size (W×H) Visible Size (W×H) Appearance Size (W×H) Appearance Thickness
930.24×523.26 mm 937.2×530.2 mm 952.2×547 mm 17.1/27.9 (Typ./Max.) mm
Appearance Features: Physical Shape Aspect Ratio Landscape/Portrait Appearance Style
Planar Rectangle 16:9 (W : H) Landscape/Portrait mode -
Other Characteristics: Surface Protection Weight Surface Treatment
-
8.60Kgs Matte surface (Haze 2%), Hard coating (3H)
Basic Information: Luminance (cd/m²) Optical Mode Contrast Ratio
400 (Typ.) AMVA3, Normally black display, transmissive 3000:1 (Typ.) (Transmissive)
Viewing Angle (L/R/U/D) Best Viewing Angle Response Speed
89/89/89/89 (Typ.)(CR≥10) Full viewing angle 6.5 (Typ.)(G to G) (ms)
Color Performance: Color Temperature Number of Colors White Field Chromaticity
9969K 16.7M (8-bit) Wx: 0.280; Wy: 0.290
1931 Color Gamut: NTSC Ratio sRGB Coverage Adobe RGB Coverage
70% 96% 73%
DCI-P3 Coverage Rec.2020 Coverage Color Gamut Description
73% 53% sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Field Variation: 1.33 (Max.)(9 points)
Refresh Rate: 60Hz
Reverse Scanning: No
Signal Electrical: Input Current Input Voltage Power Consumption
0.31/0.6A (Typ./Max.) 12.0V (Typ.) 3.72/7.2W (Typ./Max.)
Interface Features: Position Type Signal Type
Middle of the lower part of the screen body Terminal LVDS (2 ch, 8-bit)
Signal Interface: Brand Model Quantity Pin Pitch Number of Pins Pin Definition
Aviation Electronics FI-RE51S-HF 1 pcs 0.5 mm 51 pins
Backlight Characteristics: Type Position Shape Quantity Life (hours) Replaceable
WLED Side-in type light source - - 30K (Min.) -
Interface Features: Position Type WLED Driver
-
Terminal Including LED driver
Interface Details: Brand Model Quantity Pin Pitch Number of Pins Pin Definition
HAN CHERN CI0114M1HR0-NH 1 pcs 2.0 mm 14 pins
Drive Electrical: Input Current Input Voltage Power Consumption
2.49/2.65A (Typ./Max.) 24.0±1.2V 59.9/63.7W (Typ./Max.)
Packaging Type Pieces/Package Number of Boxes Dimensions of Package (L×W×H) (mm) Gross Weight (Kgs) Volume (m³) Remarks
Carton 22 1 1130×1055×655 211.00 0.7809
Pallet 22 1 1150×1055×787 225.50 0.9548
