Application Details of AUO Liquid Crystal Module P430HVN01.4
Basic Information: Panel Brand: AUO Panel Model: P430HVN01.4
Panel Size: 43 inches Panel Application: Digital Signage
Panel Type: a-Si TFT-LCD, Liquid Crystal Module Model Alias: -
Working Environment: Operating Temperature: 0 ~ 50 °C Storage Temperature: -20 ~ 60 °C
RoHS Status: RoHS Compliance Vibration Resistance: -

Pixel Characteristics: Number of Pixels: 1920(RGB)×1080, FHD Dot Pitch: 0.16335×0.49005 mm (H×V)
Pixel Layout: RGB vertical stripes Pixel Spacing: 0.49005×0.49005 mm (H×V) [51PPI]
Structural Dimensions: Display Area: 940.896×529.254 mm (H×V) Visible Area: 943.9×532.26 mm (H×V)
Appearance Size: 961.4×555.78 mm (H×V) Appearance Thickness: 17/31.9 (Typ./Max.) mm
Appearance Features: Appearance Shape: Planar rectangle Landscape/Portrait: Landscape/Portrait mode
Aspect Ratio: 16:9 (H:V) Appearance Shape: -
Other Characteristics: Weight: 7.35Kgs (Typ.) Surface Treatment: Matte surface (Haze 25%), Hard coating (3H)
Basic Information: Panel Brightness: 500 cd/m² (Typ.) Contrast Ratio: 4000:1 (Typ.) (Transmissive)
Viewing Angle: 89/89/89/89 (Typ.)(CR≥10) Optical Mode: AMVA3, Normally black display, transmissive
Viewing Angle Direction: Full viewing angle Response Time: 8 (Typ.)(G to G) (ms)
Color Performance: White Chromaticity: Wx: 0.285; Wy: 0.297 Display Colors: 16.7M (8-bit)
Color Temperature: 9122K Luminance Variation: 1.33 (Max.)(9 points)
1931 Color Gamut: NTSC Ratio: 72% sRGB Coverage: 97%
Adobe RGB Coverage: 75% DCI-P3 Coverage: 75%
Rec.2020 Coverage: 54% Color Gamut Description: sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Operating Frequency: 60Hz
Reverse Scanning: No
Backlight Characteristics: Lamp Type: WLED Replaceable: - Lamp Life: 50K (Min.) hours
Quantity: - Lamp Shape: - Position: Side-in type light source
Interface Features: Type: Terminal Position: - Lamp Driver: Including LED driver
Interface Details: Brand Model Pin Pitch Number of Pins Quantity Interface Definition
HAN CHERN CI0114M1HRL-NH 2.0 mm 14 pins 1 pcs
Drive Electrical: Voltage Input: 24±1.2V Current Input: 2.0A (Typ.)
Power Consumption: 48W (Typ.)
Signal System: LVDS (2 ch, 8-bit) Signal Logic Voltage: -
Signal Electrical: Voltage Input: 12.0V (Typ.) Current Input: 0.42/0.5A (Typ./Max.)
Power Consumption: 5.04/6.0W (Typ./Max.)
Interface Features: Type: Terminal Position: Middle of the lower part of the screen body
Terminal Details: Brand Model Pin Pitch Number of Pins Quantity Interface Definition
Hecheng 187059-5122 0.5 mm 51 pins 1 pcs

Packaging Type Pieces/Package Number of Boxes Dimensions of Package (L×W×H) (mm) Gross Weight (Kgs) Volume (m³) Remarks
Carton 10 1 1060×560×650 90.00 0.3858
Pallet 20 2 1150×1080×782 185.00 0.9712
