- 11.6寸组装屏 广告机屏LM116A047A48 POS机 一体机 平板屏幕
-
- Brand：京东方
- Size：11.6寸
- Model：LM116A047A48
- Resolution：1366*768
- Vision：89/89/89/89
- Contrast：800:1
- brightness：220cd/m²
- interface：EDP
- Operating temperature：0 ~ 50 °C 存储温度: -20 ~ 60 °C
- life：30K小时,不含驱动
- Types of：WLED
- LM116A047A48 is an 11.6-inch LCD screen, which can be used in devices such as tablets and advertising players. Its detailed parameters are as follows:
- Basic Parameters: The screen size is 11.6 inches, the panel type is a-Si TFT-LCD, the resolution is 1366×768, and the pixel arrangement is RGB vertical stripe.
- Optical Parameters: The brightness is about 220cd/m², the contrast ratio is usually between 500:1 and 800:1, the display color can reach 16.7 million, and the viewing angles (left/right/top/bottom) can reach about 89°.
- Electrical Parameters: The interface is an EDP interface, and the number of interface pins for such 11.6-inch screens is usually 30pin.
- Backlight Parameters: The backlight type is WLED, which usually has dozens of lamp beads, and the service life is generally more than 30,000 hours.
- Environmental Parameters: The operating temperature range is 0℃ to 50℃, and the storage temperature range is -20℃ to 60℃.
LM116A047A48是一款11.6寸的液晶屏，可用于平板电脑、广告机等设备。其详细参数如下：
- 基本参数：屏幕尺寸为11.6英寸，面板类型为a - Si TFT - LCD，分辨率为1366×768，像素排列为RGB垂直条状。
- 光学参数：亮度为220cd/m²左右，对比度通常在500:1至800:1之间，显示颜色可达16.7M，可视角度左/右/上/下可达89°左右。
- 电气参数：接口为EDP接口，常见的11.6寸此类屏幕接口引脚数有30pin。
- 背光参数：背光类型是WLED，通常有数十颗灯珠，使用寿命一般在30000小时以上。
- 环境参数：工作温度范围为0℃至50℃，存储温度范围是-20℃至60℃。
- 基本参数：屏幕尺寸为11.6英寸，面板类型为a - Si TFT - LCD，分辨率为1366×768，像素排列为RGB垂直条状。
- 光学参数：亮度为220cd/m²左右，对比度通常在500:1至800:1之间，显示颜色可达16.7M，可视角度左/右/上/下可达89°左右。
- 电气参数：接口为EDP接口，常见的11.6寸此类屏幕接口引脚数有30pin。
- 背光参数：背光类型是WLED，通常有数十颗灯珠，使用寿命一般在30000小时以上。
- 环境参数：工作温度范围为0℃至50℃，存储温度范围是-20℃至60℃。
